La Vague Exportée,
connect installation.
Voici quelques indications pour l'installation sonore :
1. Connect the soundcard. Main volume of soundcard at 60%. This main volume controls only the front speakers (M-AUDIO speakers)
2. Connect the computer. Master volume at 80%. The sound source is OUT 01-10 (BEHRINGER UMC 1820)
![]()
3. Connect the speakers. All unit volumes at 100%. For the Genelec speakers, unit volumes should not be changed.
4. Connect the subwoofer. Volume at 60%. Low Pass at 120Hz (image)
![]()
5. Open Ableton Lite project.
![]()
6. Hit Play (the project is already configurated to loop)
![]()
If there is any problem with audio, maybe you have to re-configure the audio settings:
Here is the troubleshooting:
1. Check again if the soundcard is connected. The sound source is OUT 01-10 (BEHRINGER UMC 1820) If it not appears you have to restart the computer.
2. Check audio output settings in Ableton Lite project.
Go to Settings > Driver Type ASIO > Audio Device UMC ASIO Driver.
![]()
3. Check if all the 8 outputs are available in Output Config.
![]()
N'hésitez pas à me contacter si quelque chose ne se passe pas comme prévu:
joaquimricardoleandro@gmail.com
+351 910009302
![]()
